Luminescent pigments

Yellow-green	Item No.	Night Glow Mode	Luminance After	Luminance After	After-Glow Time	D50	Prices Ex Work
			10 Mins(mcd/m²)	60 Mins(mcd/m²)	(Minutes)	(um)	USD/KG
	PLG-600	Yellow-Green	550	90	10000	80~100	70
	PLG-601	Yellow-Green	450	85	9000	70~80	65
	PLG-603	Yellow-green	150	10	2200	10'20	100
	PLG-604	Yellow-Green	125	16	2200	2-7um	125
	PLG-502	Yellow-Green	340	47	5550	20~30	60
	PLG-401	Yellow-Green	400	70	8500	70~80	40
	PLG-402	Yellow-Green	250	34	4000	20~30	40
	PLG-403	Yellow-Green	150	18	2500	10~20	40
Blue-green	PLG-201	Yellow-Green	280	42	3500	70~80	25
	PLG-202	Yellow-Green	180	23	2500	20~30	25
	PLG-203	Yellow-Green	130	16	1800	10'20	25
	PLG-101	Yellow-Green	270	40	3300	70~80	20
	PLG-102	Yellow-Green	170	20	2300	20~30	20
	PLG-103	Yellow-Green	125	14	1600	20'30	20
	PLG-401	Blue-Green	350	55	7500	70~80	42
	PLG-402	Blue-Green	280	38	5000	20~30	42
	PLG-201	Blue-Green	250	42	7000	35~45	27
Sky-Blue	PLB-202	Blue-Green	220	30	3500	20~30	27
	PLB-203	Blue-Green	180	20	3000	10~20	27
	PLS-201	Sky-Blue	150	28	5500	70~80	45
	PLV-201	Violet	10	2	480	70~80	45
	PLW-101	White	66	8	890	10~20	168
	PLW-201	White	69	12	1000	25-35	188
	PLR-501	Orange-red	34	2	''	20-40	250
	PLG-401	Red	18	2	''	20-40	378
Violet	ZSG-101	Yellow-Green ZnS	20	2	250	20~30	24
	ZSG-102	Yellow-Green ZnS	20	2	250	20~30	26
	LR-301	Yellow-Green ZnS	20	2	250	20~30	26
	LY-301	Orange-red	18	2		10'20	40
	LY-301	Yellow	18	2		10'20	40
	LL-301	Green	18	2		10'20	40
	LB-301	Blue	18	2		10''20	40

Red

Note:
1) The above technical data was obtained through test in accordance with DIN67510 Part I method;
2) The after-glow time refers the time it takes for the luminance to reduce to 0.32mcd/m2 from the time when the light exciting source was moved.
3) Other larger or finer particle sizes are also available as to customer's actual application need.
4) All types can be coated for waterbased application
Packing: 1kg/5kg/10kg/25kg/drum
MOQ:1KG
Payment:T/T IN ADVANCE
